⁠Ansible Execution Node

Project overview⁠ · Contact⁠ · Support terms⁠

The mesh peer that runs playbooks inside networks your controller can't reach. Place one in each closed network — a DMZ, an OT segment, an isolated VLAN, a remote site. It dials out to your control host over mutually-authenticated TLS, receives signed jobs from the orchestrator⁠, runs them locally against reachable SSH or configured Windows/WinRM targets, and streams the output back. No inbound firewall holes, no VPN, no agent on the targets.

It is the Ansible Controller⁠'s full Ansible runtime plus receptor⁠. The inherited SSH server is not started; mesh connections originate from the node.

⁠Compare the images

All three support linux/amd64 and linux/arm64. Controller and mesh use the same release versions; choose the image for its role. GitLab integration is optional.

⁠Git approvals and execution results

The controller/orchestrator handles the optional GitLab workflow: reviewed exact-commit sync, snapshot verification and manual execution approval. Nodes receive signed job payloads; they do not clone repositories or hold Git fetch credentials. GitLab is not required for native mesh jobs.

Results return to the orchestrator for collection. The GitLab integration produces HTML, JSON and JUnit reports with provenance, distinct execution/transfer outcomes and available final Ansible recap totals. Unknown outcomes remain unresolved; collection retrieves an existing job without submitting it again.

The integration scripts and CI templates need a separate upgrade on the control side; pulling a node image alone does not install them. See sync, approvals, reports and upgrades⁠. For 100+ systems, use reviewed canaries and Ansible batches, and size each node for its target connectivity and resource capacity. Inventory host counts in reports are not license or billing metrics.

⁠Voluntary support — continue free

Interactive Bash shells in mesh images show Learn more, Sponsor, and Continue free links. The notice never waits for input, stays silent in CI and command sessions, and does not enter worker protocol output. Set ANSIBLE_CONTROLLER_SUPPORT_NOTICE=0 or create ~/.hushlogin to hide it; controller-support displays it on demand in a terminal.

• Contact Tamir Suliman for deployment assistance⁠ · Support scope and terms⁠
• GitHub Sponsors⁠
• Buy Me a Coffee⁠

Contributions and paid assistance are optional. Both controller and mesh remain open source with no host limit or purchase requirement, including fleets larger than 100 systems. The standalone controller has no automatic notice.

⁠Supported tags

Versions are cut automatically on every merge to main (Conventional Commits: feat: bumps minor, fix: bumps patch). The execution node, orchestrator, and controller always share the same version number, and each release of this image is built FROM the exact controller digest published by the same run.

See the Tags tab for the current version list. Commands below use 0.29.0 as a published example; choose your tested release and keep the three images aligned.

⁠Quick reference

• Source / Dockerfile: https://github.com/allamiro/ansible-controller⁠ (docker/mesh/Dockerfile, target execution-node)
• Mesh guide: https://github.com/allamiro/ansible-controller/blob/main/mesh/README.md⁠ · Operator runbook (enroll, rotate, evict): https://github.com/allamiro/ansible-controller/blob/main/mesh/RUNBOOK.md⁠
• Issues & feature requests: https://github.com/allamiro/ansible-controller/issues⁠
• Also published to GHCR: ghcr.io/allamiro/ansible-execution-node
• Architectures: linux/amd64, linux/arm64 — both built on native runners
• User: uid 1000 (ansible), receptor runs as PID 1 · Listening ports: none — the image inherits the controller's EXPOSE 22 metadata, but no sshd is started and nothing listens on it (so skip docker run -P)
• Health check: built in — receptorctl status on the node's local control socket, so docker compose up --wait returns only once the node is actually up
• Maintainer: Tamir Suliman

⁠What's inside

• The controller's complete Ansible runtime — current ansible-core, ansible.posix, community.general, pywinrm + NTLM, and the controller-side Python libraries their plugins need — with per-job content and node-local dependencies provisioned for your playbooks.
• receptor 1.6.7 — the mesh agent, a static binary rebuilt from the exact upstream release commit with its Go module dependencies (x/crypto, x/net, x/text) bumped to CVE-fixed versions, because the upstream binary fails this project's scanner gate.
• ansible-runner 2.4.3 — the worker that executes each streamed job.
• receptorctl — for the health check and on-node debugging.
• Entrypoint that renders receptor's config from the environment on every start and refuses to start without a certificate bundle and a work-signing public key.

⁠Start it

⁠0 — Before it can join

A node needs two things from your control plane's PKI (the mesh guide⁠ walks the request → sign → install sequence):

• Its certificate bundle — tls.crt + tls.key + ca.crt, issued by your offline CA for this node's exact name. The private key is generated on the node host and never leaves it.
• The work-signing public key — work-public.pem, the public half only. The private half stays on the control host.

Node names become the addresses you dispatch to, so name nodes after their network: exec-dmz-a, exec-ot-b, and so on.

⁠Option 1 — docker compose (recommended)

Copy mesh/compose.node.yml⁠ and mesh/node.env.example⁠ to the node host — no checkout needed — and put the bundle beside them:

.
├── compose.node.yml
├── .env                                   # copied from node.env.example
└── secrets/receptor/
    ├── issued/exec-dmz-a/{tls.crt,tls.key,ca.crt}
    └── work-signing/work-public.pem

# .env
RECEPTOR_NODE_ID=exec-dmz-a
RECEPTOR_PEERS=ctrl.example.com:27199,ctrl.example.com:27200
MESH_NODE_IMAGE=allamiro1/ansible-execution-node:0.29.0

chown -R 1000:1000 secrets/receptor/issued/exec-dmz-a   # the container reads the bundle as uid 1000
docker compose -f compose.node.yml up -d --wait          # returns once the node is HEALTHY

The node restarts with its host (restart: unless-stopped) and appears in make mesh-status on the control host.

⁠Option 2 — plain docker run

docker run -d --name mesh-node-exec-dmz-a --restart unless-stopped \
  --tmpfs /run/receptor:uid=1000,gid=1000,mode=0750 \
  -v "$PWD/secrets/receptor/issued/exec-dmz-a":/etc/receptor/tls:ro \
  -v "$PWD/secrets/receptor/work-signing/work-public.pem":/etc/receptor/signing/work-public.pem:ro \
  -e RECEPTOR_NODE_ID=exec-dmz-a \
  -e RECEPTOR_PEERS=ctrl.example.com:27199,ctrl.example.com:27200 \
  -e RECEPTOR_TLS_CERT=/etc/receptor/tls/tls.crt \
  -e RECEPTOR_TLS_KEY=/etc/receptor/tls/tls.key \
  -e RECEPTOR_TLS_CA=/etc/receptor/tls/ca.crt \
  -e RECEPTOR_WORK_PUBKEY=/etc/receptor/signing/work-public.pem \
  allamiro1/ansible-execution-node:0.29.0

No -p flags: nothing listens in a node (the inherited EXPOSE 22 is metadata only). It needs just outbound TCP to the control host on 27199 (ingress A) and 27200 (ingress B), and SSH reachability to its targets.

⁠Then, on the control host

Add the node to mesh/config/pools.yml (and a zone in zones.yml) and dispatch:

make mesh-ping NODE=exec-dmz-a
make mesh-run NODE=exec-dmz-a PLAYBOOK=site.yml INVENTORY=inventory/dmz.ini

⁠Configuration reference

⁠Environment variables

All values are validated against a strict character set before being rendered into receptor's configuration, so an environment value cannot inject extra receptor actions.

⁠Mounts

⁠Adding Python dependencies for your playbooks

Plugins that need Python packages on the machine running Ansible — cloud inventory SDKs like boto3 are the classic case — need them on the node, since that is where the playbook runs. Extend the image once, exactly as the controller does:

FROM allamiro1/ansible-execution-node:0.29.0
USER root
COPY node-requirements.txt /tmp/node-requirements.txt
RUN pip3 install --no-cache-dir --break-system-packages -r /tmp/node-requirements.txt \
 && rm /tmp/node-requirements.txt
USER ansible

Pin the versions in node-requirements.txt, build it as your site tag, and set MESH_NODE_IMAGE to it.

⁠Health and troubleshooting

⁠Security posture

• No certificate, no entry. Mutual TLS is mandatory; the node presents its own certificate and verifies the ingress presents one signed by your CA for its identity. There is no plaintext fallback (short of the loud RECEPTOR_INSECURE_DEV escape hatch).
• Nodes dial out only. No listener for the mesh, no SSH server, no published ports. Your inbound firewall rules stay exactly as they are.
• Signed work only. Every job is verified against the control plane's signing key before execution, so even a compromised or partner-operated node can run jobs but never inject them.
• Unprivileged. receptor runs as PID 1 under uid 1000; the control socket is owner-only and lives on tmpfs.
• Per-job credential hygiene — an SSH key that arrives with a job is destroyed by the worker on exit, even without a control-plane connection. Abrupt process or host failure can retain data; inspect and clean up according to the runbook.
• Every published image is Trivy-scanned (fails on fixable CRITICAL/HIGH — which is why receptor is rebuilt from source with patched dependencies) and cosign-signed keylessly via GitHub OIDC. Verify before you run:

cosign verify \
  --certificate-identity-regexp 'https://github\.com/allamiro/ansible-controller/\.github/workflows/docker-publish\.yml@.*' \
  --certificate-oidc-issuer https://token.actions.githubusercontent.com \
  docker.io/allamiro1/ansible-execution-node:latest

⁠License

Apache License 2.0⁠ — see the GitHub repository for source, CI definitions, and contribution guidelines.
