fdebijl/synopticon repository overview

Synopticon supplements Synology Photos' face recognition. It syncs your photo library from the NAS, runs an ensemble face pipeline over it, groups the faces, cross-references the groups against the people Synology already knows, and — only after you approve each suggestion — writes the corrections back through Synology Photos' Person API. It also finds and removes duplicate photos.

Everything before the apply step is read-only toward your NAS, and writes are dry-run by default.

📖 Full documentation, CLI reference and configuration: github.com/fdebijl/synopticon⁠

⁠Tags

linux/amd64 only — NVIDIA ships no arm64 CUDA wheels.

⁠Quick start

The entrypoint is synopticon, so anything after the image name is a subcommand. Start with the web GUI: it walks you through NAS credentials, downloads the models, and runs every job with live progress.

mkdir -p data models

docker run -d --name synopticon \
  -p 127.0.0.1:8686:8686 \
  -v "$PWD/data:/data" \
  -v "$PWD/models:/models" \
  -e SYNOPTICON_CONFIG=/data/config.toml \
  fdebijl/synopticon:cpu web --host 0.0.0.0

Open http://127.0.0.1:8686⁠ and follow the setup wizard.

⚠️ --host 0.0.0.0 is required inside a container (the default bind is 127.0.0.1, unreachable from outside). Keep the access control on the host side by publishing to 127.0.0.1:8686 as above — the GUI is unauthenticated until you finish the wizard.

⁠docker compose

services:
  synopticon:
    image: fdebijl/synopticon:cpu       # :gpu on an NVIDIA host
    command: ["web", "--host", "0.0.0.0"]
    ports:
      - "127.0.0.1:8686:8686"
    environment:
      # Keeps the wizard-written config on the volume
      - SYNOPTICON_CONFIG=/data/config.toml
      # Optional — the wizard can store these instead:
      # - SYNOPTICON_NAS__URL=https://your-nas.example.com
      # - SYNOPTICON_NAS__ACCOUNT=photos-bot
      # - SYNOPTICON_NAS__PASSWORD=...
      # - SYNOPTICON_NAS__OTP_CODE=...       # first login only, if 2FA is on
    volumes:
      - ./data:/data
      - ./models:/models
    restart: unless-stopped

Run docker compose up -d, then open http://127.0.0.1:8686⁠.

⁠Volumes

Mount both. They are the entire state of a Synopticon install — portable between hosts, and between Docker and a bare-metal run.

⁠Configuration

Every setting is editable in the GUI, or via config.toml on /data, or per-key with environment variables shaped SYNOPTICON_<SECTION>__<KEY> (note the double underscore):

Full list: Configuration in the README⁠.

⁠Running jobs without the GUI

The same image runs one-shot commands. Against an already-configured /data:

alias syn='docker run --rm -v "$PWD/data:/data" -v "$PWD/models:/models" \
  -e SYNOPTICON_CONFIG=/data/config.toml fdebijl/synopticon:cpu'

syn check                # verify NAS connectivity (read-only, fast)
syn models download      # fetch model weights
syn sync                 # pull photos, people and existing labels
syn extract              # detect faces — the long pass, resumable
syn cluster              # group faces and cross-reference them
syn apply                # dry-run; add --apply to write back

Deduplication is a shorter, separate flow off the same sync:

syn sync --hash          # one-time: hash every original (slow, resumable)
syn dedupe --exact       # dry-run; add --apply to delete

extract and sync commit per photo, so you can interrupt them and re-run at any time. Every command is documented in the CLI reference⁠.

If you'd rather not run jobs by hand at all, the GUI's Schedules page puts sync, extract, cluster and friends on a cron timer inside the long-running web container — no cron daemon needed.

⁠GPU

Use the gpu tag on a host with a recent NVIDIA driver and the NVIDIA Container Toolkit. No system CUDA toolkit is needed — the CUDA and cuDNN runtimes ship in the image.

docker run --rm --gpus all \
  -v "$PWD/data:/data" -v "$PWD/models:/models" \
  -e SYNOPTICON_CONFIG=/data/config.toml \
  fdebijl/synopticon:gpu extract

Only face detection benefits; everything else is unaffected. A GPU run and a CPU run share the same /data, so a common pattern is to do the initial catch-up on a GPU box and copy data/ to a long-lived CPU deployment.

⁠Notes for long-lived deployments

• Keep it to one replica. The default SQLite backend is single-writer. (PostgreSQL is supported, but it doesn't make the app multi-instance.)
• Pin the container to one node on Swarm/Kubernetes so it keeps seeing the same /data and /models.
• No HEALTHCHECK is baked in, because the same entrypoint serves one-shot commands. Add one at the service level if you want it, pointed at GET /api/health:

  healthcheck:
    test: ["CMD", "python", "-c", "import urllib.request,sys; sys.exit(0 if urllib.request.urlopen('http://127.0.0.1:8686/api/health').status==200 else 1)"]
    interval: 30s
    timeout: 10s
    retries: 5
    start_period: 60s


  Copy
  Long jobs can make a strict healthcheck kill the container — loosen it if that happens.
• TLS is not terminated in the container. Publish to loopback and put nginx, Caddy or Traefik in front. uvicorn honours X-Forwarded-Proto, so the session cookie's Secure flag follows automatically.
• Model weights are not bundled (mixed upstream licenses). models download fetches the two auto-downloadable detectors and ArcFace; two optional embedders need a manual export, described in the repo.

⁠Compatibility

Any NAS running Synology Photos on DSM 7.x. API versions are discovered at runtime rather than hardcoded, so firmware differences are tolerated; if a write endpoint is missing on an older DSM it fails loudly instead of corrupting anything.

⁠Links

• Source, docs and issues: github.com/fdebijl/synopticon⁠
• Safety model (what can write, and what gates it): README⁠
• License: MIT

Parts of this codebase were created by a large language model, in particular models provided by Anthropic.
