⁠✅️ Multipass

Grafana-opinionated authenticating and authorizing reverse proxy

Multipass is an opinionated authenticating and authorizing reverse proxy for Grafana and the observability systems around it. It puts login, access control, and auditability at the edge, so Grafana and upstream backends do not each need their own authentication and authorization setup.

It handles browser authentication with OIDC, evaluates authorization from centrally managed identity data, and forwards the headers or tokens each backend expects. In front of Grafana, Prometheus, Loki, OpenSearch, Kibana, VictoriaMetrics, and similar systems, Multipass becomes the single control point for access.

It runs in two modes:

1. web for browser-based tools and dashboards.
2. api for programmatic systems that expect tokens or trusted headers.

Single sign-on. Tenant isolation. Full audit trail. Zero backend changes.

⁠Why Multipass?

Observability and operations tools rarely agree on how access should work. One wants OIDC, another expects headers, another wants JWTs. The result is duplicated setup, uneven access control, and too much backend-specific glue.

Multipass solves that at the edge:

• OIDC SSO — one browser login flow across the stack
• OIDC/JWT group authz — one authorization model driven directly from token claims
• Two delivery modes — web for UI-oriented tools, api for systems that expect tokens or headers
• Backend translation — tenant headers, JWT passthrough, or trusted web headers depending on what the backend expects
• Data minimization — keep identity, authorization, and audit decisions at the edge without pulling more backend data into Multipass than necessary
• Auditability — access decisions logged in one place and easy to ship onward

Authorization is designed in two layers:

• External IdP groups or roles come from the validated JWT unchanged
• Multipass maps those external values to internal roles such as admin, devops, dev, and man
• Tenant access and temporary PIM approvals use the internal roles

⁠Supported Applications

• jwt: JWT-authenticated systems (LGTM, OpenSearch, Elasticsearch) - see API.md⁠
• prometheus: Prometheus-compatible systems (Grafana, Loki, Mimir, Tempo, Thanos, VictoriaMetrics, Cortex, Prometheus, Alertmanager, Jaeger, SigNoz)
• web: Header-authenticated web proxy (Grafana, Kibana, OpenSearch, VictoriaMetrics) - see WEB.md⁠

⁠Architecture

Multipass sits both in front of Grafana for browser sign-in and on the datasource path between Grafana or API clients and the LGTM backends.

        Browser users
            |
            | web login + session
            v
    +-----------------+        +---------------+
    |    Multipass    |------->| OIDC provider |
    |  browser edge   |        +---------------+
    +-----------------+
            |
            | trusted user headers
            v
        +---------+
        | Grafana |
        +---------+
            |
            | datasource proxy
            v
  +-------------------+        +------------+
  |     Multipass     |------->| Audit sink |
  |  datasource edge  |        +------------+
  +-------------------+
    v       v       v
+------+ +-------+ +-------+
| Loki | | Mimir | | Tempo |
+------+ +-------+ +-------+

⁠Configuration

See config.example.yaml⁠ for complete examples.

For a realistic local profile backed by an external OIDC provider, use config.oidc.yaml⁠. This keeps Multipass on oidc and token, so moving from local OIDC to production OIDC is mostly an issuer and client configuration change instead of a provider swap.

Start Multipass by passing exactly one config file argument:

./multipass config.oidc.yaml
go run ./cmd/multipass config.oidc.yaml

⁠URL Routing

Requests are routed by backend name: http://multipass:8080/<backend>/<path>

• http://multipass:8080/loki/loki/api/v1/query → http://loki:3100/loki/api/v1/query
• http://multipass:8080/grafana/api/dashboards → http://grafana:3000/api/dashboards

⁠Deployment

Configure backends: Edit k8s/configmap.yaml⁠ with your backend endpoints:

backends:
  loki:
    type: prometheus
    endpoint: http://loki.monitoring.svc.cluster.local:3100

  opensearch:
    type: jwt
    endpoint: https://opensearch.logging.svc.cluster.local:9200

Deploy to cluster:

kubectl apply -f k8s/

Deploy with in-cluster OIDC provider:

kubectl apply -k k8s/oidc/

This overlay keeps Multipass on oidc and token while pointing OIDC at oidc-provider.monitoring.svc.cluster.local:8081.

This creates:

• ConfigMap: Backend configuration and OIDC settings
• Deployment: 2 replicas with health checks, shared browser sessions, and resource limits
• Service: ClusterIP service on port 8080

Verify:

kubectl get pods -n monitoring -l app=multipass
kubectl logs -n monitoring -l app=multipass

⁠Development

See doc/DEV.md⁠ for local development, testing, build modes, and release instructions.

Use the external OIDC profile when you want Multipass to behave like production integrations.

⁠License

MIT
