tristanteu/snapraid-ui repository overview

⁠SnapRAID UI

A modern web interface for SnapRAID⁠.
Run sync and scrub, schedule jobs and keep an eye on disk health, all from your browser.

⁠✨ Features

• Array health at a glance: last sync and scrub, scrub coverage, next scheduled job
• One-click commands: sync, scrub, status, diff, check, fix, with live output over WebSocket
• Scheduler: cron-based sync and scrub jobs, no crontab editing
• Disk overview: usage, file counts, fragmentation and parity headroom per disk
• SMART monitoring and disk power control (spin down / up)
• Logs: history of every run with full output
• Config management: edit multiple snapraid.conf files, excludes and pool settings
• English and German UI

⁠🐳 Quick start with Docker

The image ships with SnapRAID 14.9, so nothing needs to be installed on the host.

docker run -d --name snapraid-ui \
  --privileged \
  -p 3000:80 \
  -v ./snapraid:/app/snapraid \
  -v /mnt/disk1:/mnt/disk1 \
  -v /mnt/disk2:/mnt/disk2 \
  -v /mnt/parity:/mnt/parity \
  tristanteu/snapraid-ui:latest

Open http://localhost:3000⁠ and add your snapraid.conf in Manage Configurations.

Mount your disks at the same paths as on the host, so the paths in snapraid.conf stay valid. Parity and content locations must be writable. --privileged is only needed for SMART data and disk power.

⁠Docker Compose

curl -O https://raw.githubusercontent.com/firsttris/snapraid-ui/master/docker/docker-compose.yml
# add your disks under volumes:, then
docker compose up -d

For Podman with systemd, use the Quadlet files in docker/⁠.

⁠Configuration

Using your own SnapRAID binary: mount it and point SNAPRAID_BIN at it. It needs to be version 14.0 or newer, because the UI parses SnapRAID's structured log output.

  -v /usr/bin/snapraid:/usr/bin/snapraid:ro \
  -e SNAPRAID_BIN=/usr/bin/snapraid \

⁠Image tags

⁠🛠️ Development

Requires Node.js 22+ and Deno 2.5+.

git clone https://github.com/firsttris/snapraid-ui
cd snapraid-ui
./install.sh
./start.sh           # uses ./snapraid and the snapraid binary on your PATH
./start.sh --demo    # sandbox with fake disks, no real array or SnapRAID install needed

Frontend runs on http://localhost:3000⁠, backend API on http://localhost:8080⁠. Ctrl+C stops both.

--demo runs dev/setup.sh, which builds a pinned SnapRAID into dev/bin/ (needs curl, gcc, make) and creates dev/sandbox/ with three data disks, a parity disk and a few pending changes. dev/setup.sh --reset starts over.

pgrep -af "src/main.ts"                                   # show running backends
pkill -f "deno task dev"; pkill -f "deno run.*src/main.ts"
pkill -f "vite dev"

⁠Building the image locally

docker build -f docker/Dockerfile -t snapraid-ui .

Pushing a v* tag publishes a multi-arch image to Docker Hub via GitHub Actions.

⁠Stack

• Backend: Deno + Hono, WebSocket for live output, file-based storage
• Frontend: React 19, TanStack Start/Router/Query, Tailwind CSS, Paraglide i18n
• Container: Nginx reverse proxy, Supervisor, bundled SnapRAID

⁠🤝 Contributing

Issues and pull requests are welcome. Please run npx biome check, npm run typecheck and the tests (deno test in backend/, npm test in frontend/) before opening a PR.

⁠📄 License

MIT
